RJ 45 (HLE002) |
|
RJ 45 1x1 PORT With LED (Transformer) |
Products summary |
|
L/T: 4 Week |
|
P/N:HLE002 |
|
MATERIALS INSULATOR:GLASS FILLED POLYESTER UL94v-0 CONTACT:PHOSPHOR BRONZE T=0.35mm PLATING:GOLD OVER NIKET SHIELDING:0.2mm THICKNESS COPPER ALLOY WITH NICKEL PLATED OPERATING: 750 CYCLES MIN. PCB RETENTION PRE-SOLDER: 1LB MIN
ELECTRICAL VOLTAGE RATING: 125 VAC CURRENT RATING: 1.5 AMP INSULATION RESISTANCE: 500 MEGOHMS CONTACT RESISTANCE: 30 MILLIOHMS MAX DIELECTRIC STRENGTH: 1000V AC RMS 50Hz. 1MN
ENVIRONMENTAL TEMPERATURE RANGE:-40 TO +85 RELATIVE HUMIDITY: 90º~95%(40+/-2º) |
|
